| 型号 | 订货号 | 扭矩范围 | 方头尺寸 | 长度 | 重量 |
| Nm | mm | kg | |||
| DDT0002 | 860100001 | 0.2-2 | 1/4"Hex | 72 | 0.64 |
| DDT0005 | 860100002 | 0.5-5 | 1/4"Hex | 72 | 0.64 |
| DDT0020 | 860100003 | 2-20 | 1/4"Hex | 72 | 0.64 |
| DDT0022 | 860100004 | 2-20 | 1/4"Sq | 72 | 0.64 |
| DDT0025 | 860100005 | 2.5-25 | 3/8"Sq | 72 | 0.64 |
| DDT0075 | 860100006 | 7.5-75 | 3/8"Sq | 72 | 0.64 |
| DDT0180 | 860100007 | 18-180 | 1/2"Sq | 72 | 0.64 |
| DDT0250 | 860100008 | 25-250 | 3/4"Sq | 72 | 0.64 |
| DDT0500 | 860100009 | 50-500 | 3/4"Sq | 105 | 1.4 |
| DDT1400 | 860100010 | 140-1400 | 1"Sq | 115 | 1.7 |
| DDT3000 | 860100011 | 300-3000 | 1-1/2"Sq | 178 | 1.8 |
| DDT5000 | 860100012 | 500-5000 | 2-1/2"Sq | 198 | 1.8 |
